Name: 6 prievadų, 4 PoE komutatorius UTP6306S-PSB
Brand: Utepo
SKU: SWITCHUTP6306S-PSB
Price: 216.08 EUR
Availability: InStock

6 prievadų, 4 PoE komutatorius UTP6306S-PSB

Aprašymas

4*10/100/1000 Base-T Po E RJ-45 prievadai
2*1000 Base-X SFP prievadų
1*RJ-45 konsolės prievadas
Darbinė temperatūra: -40 ℃ ~ 75 ℃
Perteklinis maitinimo šaltinis
8k V kontaktinis išlydis, 12k V oro iškrovimas ESD apsauga
Metalinio korpuso dizainas be ventiliatoriaus
DIN bėgelio montavimas

Pagrindinis
Įrenginys:UTP3306 TS-PSD
Downlink prievadai:4*10/100/1000 Base-T Po E++ RJ-45(Auto-MDI/MDI-X)
Uplink prievadai:1*10/100/1000 Base-T RJ-451*1000 Base-X SFP
Led indikatoriai:1*PWR, power supply indicators1*Link/Act, SFP port state indicators
Dydis:294mm*180mm*44mm
Įeinanti įtampa:100~240 V AC, 50~60 Hz
Energijos sunaudojimas:≤370 W (Full load including Po E)
Medžiaga:Metal shell
Montavimas:Rack/Desktop/Wall mounted
Standartai:IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1 D, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
Persiuntimo režimai:Store and Forward
MAC adresų lentelė:2k, support auto learning
Perjungimo talpa:12 Gbps/non-blocking
Paketų persiuntimo greitis:8.928 Mpps
Port Buffer:1 MB
Jumbo Frame:9716 Bytes
Po E standartas:IEEE 802.3af/at/bt
Po E maitinimo tipas:End-span
Po E išdėstymas:3/6/4/5(+), 1/2/7/8(-)
Po E biudžetas:90 W max for each port, 360 W max for whole switch
Darbo sąlygos temepratūra:-10℃~50℃, 5%~95% (Non-condensation)
Saugykla:-40℃~70℃, 5%~95% (Non-condensation)
Sertifikatai:CE, FCC
Sistemos informacija:System, Hardware, Time and Firmware
IP būsena:IP Interfaces, IP Routes and ARP Table
Sistemos pranešimai:System Log Information
Detalūs sistemos pranešimai:ID and Message
MAC adresų lentelė:MAC Address Table: Type, VLAN, MAC Address, CPU and Port Number
VLANs:Membership and Ports
Prievadai:Traﬃc Overview and Detailed Statistics
LACP:System Status, Port Status and Port Statistics
Apsauga nuo perkaitimo:Thermal Protection Port Status
Green Ethernet:Port Power Savings Status
Po E statusas:Power Over Ethernet Status
LLDP:Thermal Protection Port Status
Loop Protection:Loop Protection Status
Aprėpiantys protokolai:Bridge Status, Port Status and Port Statistics
IGMP Snooping:IGMP Snooping Status, Groups Information and IPv4 SFM Information
MLD Snooping:MLD Snooping Status, Groups Information and IPv6 SFM Information
DHCP:Server, Snooping Table, Relay Statistics and Detailed Statistics
Saugumas:Port Security, Access Management Statistics, 802.1 X, ACL Status and AAA
Qo S:Qo S Statistics and QCL Status
IP Conﬁg:IP Conﬁguration, IP Interfaces and IP Routes
IP būsena:IP Interfaces, IP Routes and ARP Table
DHCP serveris:DHCP Server Mode Conﬁguration, Excluded IP and Pool
NTP:NTP Conﬁguration
Timezone:System Timezone Oﬀset and UTC time
SNMP:System, Trap, Communities, Users, Groups, Views and Access
Sistemos pranešimai:System Log Conﬁguration
Prievadai:Port Conﬁguration
Aggregation:Static and LACP
Mirroring:Mirror and Mirror Port Conﬁguration
Apsauga nuo perkaitimo:Thermal Protection Conﬁguration
Green Ethernet:Port Power Savings and Port Conﬁguration
DDM:DDM Conﬁguration, DDM Overview and DDM Detailed
Po E nuostatai:Power Over Ethernet, Po E Power Supply and Po E Port Conﬁguration
Po E statusas:Power Over Ethernet Status
MAC adresų lentelė:Aging Conﬁguration, MAC Table Learning and Static MAC Table Conﬁguration
PTP:PTP Clock Conﬁguration and PTP Status
VLANs:Global VLAN and Port VLAN Conﬁguration
Balso VLAN:Voice VLAN Conﬁguration and Voice VLAN OUI Table
GVRP:GVRP Global and Port Conﬁguration
Prievado izoliacija:Port Group and Port Isolation
Loop Protection:General Settings and Port Conﬁguration
Aprėpiantys protokolai:Bridge Settings, MSTI Mapping, MSTI Priorities, CIST Ports and MSTI Ports
IPMC profilis:Proﬁle Table and Address Entry
MEP:Maintenance Entity Point
ERPS:Ethernet Rapid Ring Protection Switching
IGMP Snooping:Basic Conﬁguration, VLAN Conﬁguration and Port Filtering Proﬁle
IPV6 MLD Snooping:Basic Conﬁguration, VLAN Conﬁguration and Port Filtering Proﬁle
LLDP:LLDP Parameters and LLDP Interface Conﬁguration
Vartotojai:Users Conﬁguration
Privilegijų lygiai:Privilege Level Conﬁguration
SSH:SSH Conﬁguration
HTTPS:HTTPS Conﬁguration
Prievado saugumo riba:System and Port Conﬁguration
Prieigos valdymas:Access Management Conﬁguration
802.1 X:Network Access Server Conﬁguration
ACL:Ports, Rate Limiters and Access Control List
ARP Inspection:Port Conﬁguration, VLAN Conﬁguration, Static Table and Dynamic Table AAA RADIUS and TACACS+
Port Classiﬁcation:Qo S Ingress Port Classiﬁcation
Prievado politika:Qo S Ingress Port Policers
Eilės politika:Qo S Ingress Queue Policers
Prievado planavimas:Qo S Egress Port Schedulers
Prievado formavimas (port shaping):Qo S Egress Port Shapers
Prievado žymos žymėjimas:Qo S Egress Port Tag Remarking
Prievado DSCP:Qo S Port DSCP Conﬁguration
DSCP-Based Qo S:DSCP-Based Qo S Ingress Classiﬁcation
DSCP vertimas:DSCP vertimas
DSCP klasifikacija:DSCP klasifikacija
Qo S valdymo sąrašas:Qo S Control List Conﬁguration
Storm Policing:Global Storm Policer Conﬁguration
Ping:ICMP Ping
Kabelio diagnostika:Cable Status
Procesoriaus apkrova:CPU Load Information
Įrenginio paleidimas iš naujon:Restart the Device
Gamykliniai nustatymai:Gamykliniai nustatymai
Programinės įrangos atnaujinimas:Software Upload
Programinės įrangos pasirinkimas:Software Image Selection
Konfigūracija:Download, Upload, Activate and Delete
